Hikvision NVR DS-7608NI-I2/8P

0 out of 5

612,15

PVM įskaičiuotas

  • 8 kanalų NVR
  • 8 PoE sąsajos
  • 2 SATA sąsajos (iki 6TB kiekvienam HDD)
  • Įeinantis srautas iki 80Mbps
  • Iki 12 Mpx rašymo raiška
  • H.265/H.265+/H.264/H.264+/MPEG4
  • Garso įvestis/išvestis
  • Pavojas signalo įvestis/išvestis
  • HDMI/VGA išvestis
Produkto statusas: Turime sandėlyje (Pristatymas 1-3 d.d.)Pagal užsakymą (Pristatymas iki 5-10 d.d) Produkto kodas: 85c58e205cdb

Aprašymas

Model DS-7608NI-I2/8P DS-7616NI-I2/16P
Video/Audio input IP video input 8-ch 16-ch
Up to 12 MP resolution
Two-way audio 1-ch, RCA (2.0 Vp-p, 1kΩ)
Network Incoming bandwidth 80 Mbps 160 Mbps
Outgoing bandwidth 256 Mbps
Remote connection 128
Video/Audio output Recording resolution 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF /CIF/QCIF
HDMI output resolution 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz,

1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

VGA output resolution 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio output 1-ch, RCA (Linear, 1 KΩ)
Decoding Decoding format H.265/H.264/H.264+/MPEG4
Live view / Playback resolution 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF /CIF/QCIF
Synchronous playback 8-ch 16-ch
Capability 4-ch @ 4K, or 16-ch @ 1080p
Hard disk SATA 2 SATA interfaces for 2HDDs
Capacity Up to 6TB capacity for each HDD
External interface Network interface 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
USB interface Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm in/out 4/1
POE Interface (for /P series NVR only) Interface 8 RJ-45 10/100 Mbps self-adaptive Ethernet interfaces 16 RJ-45 10/100 Mbps self-adaptive Ethernet interfaces
Power ≤120W ≤200W
Supported standard IEEE 802.3 af/at
General Power supply 100 to 240 VAC, 50 to 60 Hz
Power ≤180 W ≤280 W
Consumption (without hard disk) ≤15 W (without enabling PoE)
Working temperature -10 to +55ºC (14 to 131ºF)
Working humidity 10 to 90 %
Chassis 380mm chassis
Dimensions(W × D × H) 380 × 290 × 45mm (15.0″ × 11.4″ × 1.8″)
Weight(without hard disk) ≤ 3 Kg (6.6 lb)

Papildoma informacija

Svoris 2,365 kg
Gamintojas

Hikvision
